The news has recently been dominated by things of a nautical nature, thanks to the apparent loss of the Titan minisubmarine during a dive on a prominent wreck in the North Atlantic. I figured I should collect my thoughts (refined during discussions on the discord) and post them here.
First, a caveat. I am not an expert in deep-ocean operations, and I have no specific knowledge of OceanGate or this submersible beyond what I've read since this all started. That said, I've had some interest in this general field for a while, and have read several books on military deep-sea operations before all this blew up.
It's worth starting with a review of what we know about Titan. Most of this comes from a 2019 profile in Smithsonian. The sub's pressure hull is composed of a carbon-fiber cylinder with two titanium hemispheres on the ends. This is lighter than a conventional metal hull would have been, which in turn made it a lot easier to solve the basic problem of submarines: a fully-loaded submarine has to have the same density as water. With deep-diving submersibles, the hull is generally too heavy, and they have to attach additional flotation, something Titan was able to avoid.
That said, this is not the best use-case for carbon fiber.1 Carbon fiber's best properties are stiffness and extremely high tensile (tearing) strength, but a submarine's hull is in compression (crushing). There's also the problem that carbon fiber is a less reliable material than metal, with its properties depending heavily on exactly how it is built (it is much stronger with the grain of the fibers than across them, for instance). While there isn't any reason that you couldn't use carbon fiber for this role, there have been disquieting reports about OceanGate's practices with regards to safety and inspections. They also seem to have relied heavily on their acoustic monitoring system, which was supposed to hear fibers breaking well before any failures became catastrophic. I don't have the familiarity with carbon fiber as a material to have a strong opinion on this.2 The basic idea certainly doesn't sound crazy, but it's far from clear that it was tested and implemented well.
With that out of the way, we can turn to what we do know. Communication was lost with the submarine about 1 hour and 45 minutes into the mission, which is generally reported to have taken about 2 hours to reach the objective. This was not the first time comms had been lost during a dive, and Titan may have had only limited capability to navigate without outside help. Procedure was to wait for a while to reestablish communications, and if that couldn't be done, to drop ballast and abort. After that, we have had no definite contact with the submarine, despite extensive searches of both the sea surface and the bottom near the area.
That leaves three basic options for what happened to the submarine, and we can look at each of them in turn. First, there's the possibility of a catastrophic failure of the hull, killing everyone aboard almost instantly. Given the untested hull, this is fairly likely, and leaves a fairly large area where the remains of the submarine could be. The only external evidence would be a rather loud bang as water under hundreds of atmospheres of pressure came rushing in. I am sure that someone has asked the Navy to check the SOSUS tapes, but sound does weird things in the ocean, and the systems have been drawn down since the Cold War, so it may or may not have been captured.
The second option is that Titan is trapped on the bottom, and we need to free it before the crew runs out of air. I find this significantly harder to believe, assuming reports about the ballast system are correct. It appears that there are several options for jettisoning ballast in an emergency, including two (pipes which can be rolled off by getting everyone to the same side of the sub and a strap that would dissolve after 16 hours in the water) that do not require power. It doesn't appear that there are any large volumes which are normally buoyant but which could have flooded in an accident, as happened on Pieces III, leaving entanglement with an object on the ocean floor as the only way the submarine could be trapped intact. This seems unlikely given the general lack of obstructions on the floor of the deep ocean. The only real candidate is the wreckage they dove on, which would require the pilot to have gotten in too close after losing communications, which seems unlikely.
That leaves the possibility that they were able to surface after the loss of comms, and are drifting around the North Atlantic. I rate this one as more likely than being trapped on the bottom, for reasons described above, but less and less likely as time goes on, as we are quite good at finding things at sea. At one point, snorkel detection was a major ASW technique, and while Titan is not large, it's definitely larger than a snorkel. It is also worth pointing out that those aboard would still be trapped inside, as access comes through one of the titanium hemispheres, which is bolted on before descent. This isn't an inherently insane idea, as it removes a potential point of failure that a hatch would be, particularly in a carbon-fiber structure, but it would need to be matched with a reliable system for getting help once on the surface. Reports seem to indicate that they do not have such a system, one of many poor engineering decisions on the part of OceanGate.
A last word on the banging noises reported on the 21st. Yes, they could have come from the submarine, and the timing is suggestive of human activity. But the oceans are very noisy, and sonobuoys are not optimized to listen for things 4 km down. Particularly given the rather limited capabilities of a sonobuoy relative to a full-scale passive sonar (none of which appear to be on the scene), this shouldn't be read too strongly. Particularly in light of the Coast Guard's announcement of the discovery of a debris field, which came out just as I was finishing up this post.
A year later, this post has held up quite well. The submarine imploded just as I predicted, and the Navy was able to pull the information off the SOSUS tapes. The investigation is still ongoing, but nothing seems to have come out which contradicts what we knew at the time I wrote this.
1 For those who are confused about what it is, "carbon fiber" is the generic term for what is more accurately called "carbon fiber reinforced polymer". Pure carbon is very strong but also very brittle, so the best way to use it is to create fibers by heating other material, then weave those into a fabric, which is then covered in plastic, formed into shape and cured. This allows the plastic and fiber to reinforce each other, giving the best of both worlds. ⇑
2 I learned a bit about it in college, but my materials professor was the worst I had in my entire time in school, and I haven't had to think about it since. ⇑
